Features
- Computerized tools set-up.
- 3 scoring scoring profiles (point to point, male to narrow female, male to wide female).
- Motorized switchover between scoring profiles. motorized scoring depth adjustment to meet different caliper.
- Tungsten steel blades ensure clean slitting edges.
- Non-stop order change could be accomplished with combination of double slitter scorers.
- Automatic alignment for slitting trims (Option)
- Shredder with pendent side trim suction device (Option)
- Mark-slitting function (Option)
- Double scoring device (Option)
Main Technical Data
- Available width: 1400mm, 1600mm, 1800mm, 2000mm, 2200mm, 2500mm
- Designed speed: 250m/min
- Min. slit-to-slit distance: 150mm
- Min. score-to-score distance: 140mm, 0mm (double scoring device)
- Tool set-up precision: ±1mm
- Tool setup: less than 20s
