Features
- Dual servo knife bar motors and precise transmission ensure cutting accuracy.
- Low inertia rotary knife roll dramatically reduces matched power, improves short sheet chopping speed.
- Anti-crush roller at both in-feeding and out-feeding unit, not only favorable for accurate cutting precise and also avoiding paper thickness loss.
- Surface heat treated tachometers suits for different temperature change, featuring wear resistance.
- Adjustable connection between main frame and foundation enable fine adjustment for diagonal error.
- Hard ground gear and its lubrication system, smooth transmission, lower noise and long life.
- Oil felt lubrication prolongs knife life.
- Individual variable frequency drive for in-feeding and servo drive out-feeding unit. Individual servo drive for upper and lower layer.
- Data interface with Production Management System, enabling non-stop order change with cutting-ends function.
- Error display and automatic recovery via industrial computer.
- AC cutting system
Main Technical Data
- Available width: 1400, 1600, 1800, 2000, 2200, 2500, 2800mm
- Min. cutting length: 500mm
- Designed speed: 400m/min
- Cutting precision: ±1mm (at stable speed)
- Maxi. Sheet thickness:15mm
